Single Pass SP 900
From: 71800 €
The SP 900 machine from the Single Pass range meets both ecological expectations and high-quality requirements in the packaging industry.
Water-based inks offer several significant advantages, particularly in companies focused on sustainability, safety, and quality.
Compatible with recyclable or biodegradable substrates, it ensures precise reproduction of designs while maintaining a natural finish. It offers excellent adhesion and a uniform finish on absorbent surfaces such as kraft paper or cardboard.
Its energy efficiency and ability to reduce ink waste contribute to a more environmentally friendly production process while maintaining high quality standards.
Number of colours:
Une couleur
Multicouleurs
Shape:
Forme relativement plane
Quantity:
Series
Materials:
Discover...
Technical sheet
The SP 900 Single Pass inkjet printing machine meets high-quality printing requirements for modern and customized packaging projects.
– Welded stainless steel machine frame.
– Closed body design to limit dust exposure.
– Multiple access points for print monitoring and easy maintenance.
– Equipped with the latest generation HP printheads.
– Rapid implementation thanks to Single Pass technology, allowing printing in a single pass.
– Automatic image management via a French-language RIP.
– Exclusive internal ink circulation technology for printheads.
– Dual negative pressure ink supply system that ensures perfect ink regulation.
– User-friendly interface with a color touchscreen that simplifies communication with the operator.
– Automatic printhead height calibration.
– Laser sensor to detect the arrival of the piece and initiate printing.
– Perforated conveyor belt with vacuum suction for precise positioning and adjustable mechanical guides.
– Water-based inks, which reduce environmental impact.
– Optional automatic cardboard feeder that ensures steady supply and reduces the costs of manual feeding.
– Integration possible into automated production lines, contributing to overall manufacturing process optimization (strapping machines, etc.).
Features:
Colors
Cyan – Magenta – Yellow – Black
Types and number of heads
HP head / 3 heads
Maximum printing width
900 mm
Maximum material width
2000 mm
Maximum material thickness
80 mm
Printing speeds
5 m/min – 15 m/min – 30 m/min
Resolutions
1200*300 dpi – 1200*600 dpi – 1200*1200 dpi
RIP software
Flexiprint
Interface
Ethernet
Document formats
AI / PDF / BMP / JPG / JPEG / EPS / PSD / PICT / WMF / PNG / TIFF
Compatible software
CorelDRAW – Photoshop – AutoCAD – Inkscape or any software capable of exporting to supported file formats
Operating system
Windows
Machine dimensions
4120 mm*2250 mm*2200 mm
Machine weight
1900 kg
Power
7 Kw
Option
Feeder for cardboard:
– Dimensions 2350*1750*1700 mm
– Weight 800 kg
– Power 1.5 Kw
– Support width 2500 mm
– Feed speeds 5 m/min -15 m/min – 30 m/min
– Support thickness 450 mm
Accessories available with this product
Examples of applications using this product
Find out what this product can be used for.
THERMOFLAN advantages
Over 60 years of experience
Permanent stock
Best quality/price ratio
Technical availability
